Specification
Page 2-2
IDE
One IDE interface (up to 2 IDE devices) with UDMA-33, ATA-66/100
support from embedded IDE controller
USB
Eight USB connectors compliant with USB2.0 from embedded USB
controller (4 connectors at rear panel)
S-ATA II
Four S-ATA II ports with up to 300MB/s bandwidth from ICH7
LAN
One Gb Ethernet from Realtek RTL8110 PCI controller, or
One 10/100 Ethernet from Realtek RTL8100C PCI controller
Audio
Selectable 2, 6 or 8-CH audio from ALC880 Azalia compliant CODEC
with 20-bit ADC and 24-bit DAC
- Support CD-In
- Coaxial S/PDIF-out available on rear panel
- Support Jack detection for fool-proof audio device installation
- Rear panel audio jacks configuration:
I/O
Onboard Fintek LPC bus I/O controller
Legacy peripheral interface for PS/2 keyboard & mouse, FDD, Parallel,
Serial, and IrDA (v1.0 compliant)
Support Hardware Monitoring for fan speed monitoring, CPU/System
temperature and ThermoStick temperature.
Intelligent fan speed control for CPU-fan (PWM)for quiet operation
roloCkcaJoiduA lennahc2 lennahc6 lennahc8
eulBthgiLni-eniLni-eniLni-eniL
emiLtuo-eniLtuo-oeretstnorFtuo-oeretstnorF
kniPni-ciMni-ciMni-ciM
yarGtuo-oeretsediS
kcalBtuo-oeretsraeRtuo-oeretsraeR
egnarOrefoowbuS&retneCrefoowbuS&retneC
