MPCMM0001 Chassis Management Module Software Technical Product Specification 177
Remote Procedure Calls (RPC)
Table 80. Error and Return Codes for the RPC Interface (Sheet 1 of 4)
Code #: Error Code String Error Code Description
0 E_SUCCESS Success
1 E_BPM_BLADE_NOT_PRESENT Blade isn't in the chassis.
2
E_ECMM_SVR_COMMAND_UNSUPPORTED
ECMM_SVR: Unsupported Command
Error.
3 E_CLI_MSG_SND CLI Send Message Error.
4 E_CLI_INVALID_TARGET Not a valid -t parameter.
5 E_CLI_INVALID_LOCATION Not a valid -l location.
6 E_CLI_INVALID_DATA_ITEM Not a valid -d parameter.
7 E_CLI_INVALID_SET_DATA Not a valid -v parameter.
8 E_CLI_INVALID_REQUEST CLI Invalid Request Error.
9 E_CLI_MSG_RCV CLI Receive Message Error.
10 E_CLI_NO_MORE_DATA No data found to retrieve.
11 E_CLI_DATA_TYPE_UNSUPPORTED CLI Data Type Unsupported.
12 E_ECMM_CLIENT_CONNECT_ERROR ECMM_CLIENT: RPC Connect Error.
13 E_ECMM_SVR_AUTH_CODE_FAIL Invalid auth code passed to RPC interface.
14
E_CLI_STANDBY_CMM
Operation cannot be performed on standby
CMM.
15
E_WP_INITIALIZING
The CMM is Initializing and Not Ready.
Wait a few seconds and try again.
16 E_BPM_NON_IPMI_BLADE Blade does not support IPMI.
17
E_BPM_STANDBY_CMM
BPM operation cannot be performed on
standby CMM.
18
E_BPM_NO_MORE_DATA
Couldn't delete a board from the drone
mode list.
19 E_BPM_INVALID_SET_DATA Not a valid -v parameter.
20 E_CLI_INVALID_BUFFER Internal CMM Error
21 E_CLI_INVALID_CMM_SLOT Internal CMM Error
22 E_CLI_NO_MSGQ_KEY Internal CMM Error
23 E_CLI_NO_MSGQ Internal CMM Error
24 E_CLI_NO_MSGQ_LOCK Internal CMM Error
25 E_CLI_NO_MSGQ_UNLOCK Internal CMM Error
26 E_CLI_FILE_OPEN_ERROR Internal CMM Error
27 E_CLI_CFG_WRITE_ERROR CMM Config File Error.
28 E_IMB_NO_MSGQ Internal CMM Error
29 E_IMB_NO_MSGQ_KEY Internal CMM Error
30 E_IMB_SEND_TIMEOUT Internal CMM Error
31 E_IMB_DRIVER_FAILURE Internal CMM Error
32 E_IMB_REQ_TIMEOUT A blade is not responding to IPMI requests.
33 E_IMB_RECEIVE_TIMEOUT A blade is not responding to IPMI requests.
