Intel® Desktop Board DH61AG Product Guide Order Number: G28728-001

Intel Desktop Board DH61AG Product Guide 10 Table 1. Feature Summary (continued) Audio • 10-channel (8 + 2) Intel® High Definition Audio (Intel® HD

Desktop Board Features 11 Table 1. Feature Summary (continued) Hardware Management Nuvoton W83677HG-I based subsystem, including: • Voltage sense t

Intel Desktop Board DH61AG Product Guide 12 Desktop Board Components Figure 1 shows the approximate location of the major components on the top side o

Desktop Board Features 13 Table 2. Intel Desktop Board DH61AG Components (Shown in Figure 1) Label Description A Internal stereo speakers connector

Intel Desktop Board DH61AG Product Guide 14 Figure 2. Intel Desktop Board DH61AG Components (Bottom) Table 3. Intel Desktop Board DH61AG Components

15 2 Installing and Replacing Desktop Board Components This chapter tells you how to: • Install the I/O shield • Install and remove the Desktop Bo

Intel Desktop Board DH61AG Product Guide 16 Installation Precautions When you install and test the Intel Desktop Board, observe all warnings and cauti

Installing and Replacing Desktop Board Components 17 Installing the I/O Shield This Desktop Board comes with I/O shields. When installed in the chass

Intel Desktop Board DH61AG Product Guide 18 Installing and Removing the Desktop Board CAUTION Only qualified technical personnel should perform this

Installing and Replacing Desktop Board Components 19 Installing and Removing a Processor Instructions on how to install the processor on the Desktop B

Revision History Revision Revision History Date -001 First release of the Intel® Desktop Board DH61AG Product Guide May 2011 Disclaim

Intel Desktop Board DH61AG Product Guide 20 3. Rotate the socket lever to lift the load plate away from the socket (Figure 6, A). Make sure that the

Installing and Replacing Desktop Board Components 21 4. Remove the processor from its protective cover. Hold the processor only at the edges, being

Intel Desktop Board DH61AG Product Guide 22 6. Carefully lower the socket lever (Figure 9, A) while making sure that the front edge of the load plate

Installing and Replacing Desktop Board Components 23 Installing a Processor Fan Heat Sink Intel Desktop Board DH61AG has mounting holes for a processo

Intel Desktop Board DH61AG Product Guide 24 Removing the Processor For instructions on how to remove the processor fan heat sink and processor, refer

Installing and Replacing Desktop Board Components 25 Figure 11. Installing an SO-DIMM

Intel Desktop Board DH61AG Product Guide 26 To remove an SO-DIMM from the socket, gently spread the socket’s retention arms as shown in Figure 12 to d

Installing and Replacing Desktop Board Components 27 Connecting to SATA Drives Intel Desktop Board DH61AG supports two SATA drives with two data conn

Intel Desktop Board DH61AG Product Guide 28 Figure 13. Connecting the SATA Data and Power Cables

Installing and Replacing Desktop Board Components 29 Installing a PCI Express Mini Card in the PCI Express Full-/Half-Mini Card Slot A PCI Express Ful

iii Preface This Product Guide gives information about board layout, component installation, BIOS updates, and regulatory requirements for Intel® Des

Intel Desktop Board DH61AG Product Guide 30 Figure 14. Installing a PCI Express Mini Card in the Full-/Half-Mini Card Slot

Installing and Replacing Desktop Board Components 31 Installing a PCI Express Mini Card in the PCI Express Half-Mini Card Slot A PCI Express Half-Mini

Intel Desktop Board DH61AG Product Guide 32 NOTE If you install a wireless card in the PCI Express Half-Mini Card slot, the external antenna(s) can

Installing and Replacing Desktop Board Components 33 Analog Surround Audio Header Figure 16, A shows the location of the analog surround audio header

Intel Desktop Board DH61AG Product Guide 34 Front Panel Single-Port USB 2.0 Header Figure 16, D shows the location of the front panel single-port USB

Installing and Replacing Desktop Board Components 35 Front Panel Header Figure 16, F shows the location of the front panel header. Table 9 shows the

Intel Desktop Board DH61AG Product Guide 36 Front Panel Dual-Port USB 2.0 Headers Figure 16, G shows the location of the front panel dual-port USB 2.

Installing and Replacing Desktop Board Components 37 Front Panel Audio Header The front panel audio header shown in Figure 16, I supports both Intel H

Intel Desktop Board DH61AG Product Guide 38 Connecting a System Fan You can connect a 4-pin or 3-pin system fan cable to the system fan header on the

Installing and Replacing Desktop Board Components 39 Connecting to a Power Supply The board can use the following power supplies: • External Power Su

Intel Desktop Board DH61AG Product Guide iv Terminology The table below gives descriptions of some common terms used in the product guide. Term Descri

Intel Desktop Board DH61AG Product Guide 40 CAUTION The external 19 VDC jack is the primary power input connector of Intel Desktop Board DH61AG. How

Installing and Replacing Desktop Board Components 41 Setting the BIOS Configuration Jumper NOTE Always turn off the power and unplug the power cord f

Intel Desktop Board DH61AG Product Guide 42 The three-pin BIOS jumper block enables board configuration to be done in the BIOS Setup program. Table 1

Installing and Replacing Desktop Board Components 43 Replacing the Battery A coin-cell battery (CR2032) powers the real-time clock and CMOS memory. W

Intel Desktop Board DH61AG Product Guide 44 VORSICHT Bei falschem Einsetzen einer neuen Batterie besteht Explosionsgefahr. Die Batterie darf nur du

Installing and Replacing Desktop Board Components 45 VIGYÁZAT Ha a telepet nem a megfelelő típusú telepre cseréli, az felrobbanhat. A telepeket lehe

Intel Desktop Board DH61AG Product Guide 46 . UYARI Yanlış türde pil takıldığında patlama riski vardır. Piller mümkün olduğunda geri dönüştürül

Installing and Replacing Desktop Board Components 47 To replace the battery, follow these steps: 1. Observe the precautions in "Before You Beg

Intel Desktop Board DH61AG Product Guide 48 Figure 20. Removing and Replacing the Battery

49 3 Updating the BIOS The BIOS Setup program can be used to view and change the BIOS settings for the computer. You can access the BIOS Setup prog

v Contents 1 Desktop Board Features Feature Summary ...

Intel Desktop Board DH61AG Product Guide 50 Updating the BIOS Using the F7 Function Key To use this BIOS update method: 1. Download and save the Rec

Updating the BIOS 51 NOTE Review the instructions distributed with the update utility before attempting a BIOS update. CAUTION Do not interrupt the

Intel Desktop Board DH61AG Product Guide 52

53 A Error Messages and Indicators This appendix describes error messages generated by the Desktop Board’s BIOS. The BIOS indicates these error mess

Intel Desktop Board DH61AG Product Guide 54 Table 17. BIOS Speaker Beep Codes Type Pattern Frequency/Comments F2 Setup/F10 Boot Menu Prompt One 0.5

55 B Regulatory Compliance This appendix contains the following regulatory compliance information for Intel Desktop Board DH61AG: • Safety standards

Intel Desktop Board DH61AG Product Guide 56 European Union Declaration of Conformity Statement We, Intel Corporation, declare under our sole responsib

Regulatory Compliance 57 Polski Niniejszy produkt jest zgodny z postanowieniami Dyrektyw Unii Europejskiej 2004/108/EC, 206/95/EC i 2002/95/EC. Portu

Intel Desktop Board DH61AG Product Guide 58 Deutsch Als Teil von Intels Engagement für den Umweltschutz hat das Unternehmen das Intel Produkt-Recycli

Regulatory Compliance 59 Portuguese Como parte deste compromisso com o respeito ao ambiente, a Intel implementou o Programa de Reciclagem de Produtos

Intel Desktop Board DH61AG Product Guide vi B Regulatory Compliance Safety Standards ...

Intel Desktop Board DH61AG Product Guide 60 China RoHS Intel Desktop Board DH61AG is a China RoHS-compliant product. The China Ministry of Informati

Regulatory Compliance 61 EMC Regulations Intel Desktop Board DH61AG complies with the EMC regulations stated in Table 20 when correctly installed in a

Intel Desktop Board DH61AG Product Guide 62 radio or television reception, which can be determined by turning the equipment off and on, the user is en

Regulatory Compliance 63 Korea Class B Statement Korea Class B Statement translation: This equipment is for home use, and has acquired electromagneti

Intel Desktop Board DH61AG Product Guide 64 Product Certifications Board-Level Certifications Intel Desktop Board DH61AG has the regulatory complianc

Regulatory Compliance 65 Chassis- and Component-Level Certifications Ensure that the chassis and certain components; such as the power supply, periphe

Intel Desktop Board DH61AG Product Guide 66

Contents vii Tables 1. Intel Desktop Board DH61AG Features ... 9 2. Intel Desktop Board DH

Intel Desktop Board DH61AG Product Guide viii

9 1 Desktop Board Features This chapter briefly describes the features of Intel® Desktop Board DH61AG. Table 1 summarizes the major features of the
