Raw

Card

Version

DIMM

Capacity

DRAM

Device

Technology

DRAM

Organization

# of

DRAM

Devices

# of

Physical

Devices

Ranks

# of

Row / Col

Address

Bits

# of

Banks

Inside

DRAM

Page Size

A 1 GB 1 Gb 128 M X 8 8 1 14/10 8 8K

2 GB 1 Gb 128 M X 8 16 2 14/10 8 8K

4 GB 2 Gb 256 M X 8 16 2 15/10 8 8K

4 GB 4 Gb 512 M X 8 8 1 15/10 8 8K

8 GB 4 Gb 512 M X 8 16 2 16/10 8 8K

Server and Workstation Platforms

Unbuffered / ECC Supported DIMM Module Configurations

1 GB 1 Gb 128 M X 8 9 1 14/10 8 8K

2 GB 2 Gb 256 M X 8 9 1 15/10 8 8K

2 GB 1 Gb 128 M X 8 18 2 14/10 8 8K

4 GB 2 Gb 256 M X 8 18 2 15/10 8 8K

8 GB 4 Gb 512 M X 8 18 2 16/10 8 8K

Note: DIMM module support is based on availability and is subject to change.

Note: System memory configurations are based on availability and are subject to change.

2.1.2 System Memory Timing Support

The IMC supports the following DDR3L Speed Bin, CAS Write Latency (CWL), and

command signal mode timings on the main memory interface:

• tCL = CAS Latency

• tRCD = Activate Command to READ or WRITE Command delay

• tRP = PRECHARGE Command Period

• CWL = CAS Write Latency

• Command Signal modes = 1N indicates a new command may be issued every

clock and 2N indicates a new command may be issued every 2 clocks. Command

launch mode programming depends on the transfer rate and memory

configuration.

2.1.3

System Memory Organization Modes

The Integrated Memory Controller (IMC) supports two memory organization modes –

single-channel and dual-channel. Depending upon how the DIMM Modules are

populated in each memory channel, a number of different configurations can exist.

Single-Channel Mode

In this mode, all memory cycles are directed to a single-channel. Single-channel mode

is used when either Channel A or Channel B DIMM connectors are populated in any

order, but not both.

Interfaces—Processor

Intel

Xeon

Processor E3-1200 v3 Product Family

June 2013 Datasheet – Volume 1 of 2

Order No.: 328907-001 19
